制造商:ON
The NCV7718 is a Hex Half-Bridge Driver with protection features designed specifically for automotive and industrial motion control applications. The NCV7718 has independent controls and diagnostics. The device can be operated in forward, reverse, brake, and high impedance states. The drivers are controlled via a 16 bit SPI interface and are daisy chain compatible.
Low Quiescent Current Sleep Mode
HighSide and LowSide Drivers Connected in a HalfBridge Configuration
Integrated Freewheeling Protection (LS and HS)
0.55 A Peak Current
RDS(on) = 1 ohm (typ)
5 MHz SPI Control
Compliance with 5 V and 3. 3 V Systems
Undervoltage and Overvoltage Lockout
Discriminated Fault Reporting
Overcurrent Protection
Overtemperature Protection
Under Load Detection
Daisy Chain Compatible with Multiple of 8 bit Devices
16Bit Frame Detection
Dual Source of NCV7718C
NCV7718电路图
NCV7718电路图
NCV7718电路图
NCV7718 引脚图
NCV7718 封装图
型号 | 制造商 | 描述 | 购买 |
---|---|---|---|
NCV7718DPR2G | ON | HALF BRIDGE BASED PERIPHERAL DRI | 立即购买 |
标题 | 类型 | 大小(KB) | 下载 |
---|---|---|---|
SSOP24 NB | 69 | 点击下载 | |
Hex Half-Bridge Driver | 276 | 点击下载 | |
NCV7718_PO.JPG | UNKNOW | 32 | 点击下载 |
NCV7718_AD.JPG | UNKNOW | 69 | 点击下载 |
NCV7718GEVB Bill of Materials ROHS Compliant | 74 | 点击下载 | |
NCV7718GEVB Gerber Layout Files (Zip Format) | RAR | 143 | 点击下载 |
NCV7718GEVB Schematic | 455 | 点击下载 | |
NCV7718GEVB Test Procedure | 214 | 点击下载 |
